We are excited to present the versatile PM2277, an automotive-grade flyback gate drive transformer designed to cater to a wide range of IGBT device switching needs. This 1.5W flyback transformer provides a +20V output, which can be flexibly transferred to +15V and -5V on the customer’s PC board for SiC switching on and off. The extended creepage distance EP9 platform offers a robust 2.5KV AC withstand voltage in a compact (10.2×10.5×12.5mm) SMD platform.
The PM2277 is purpose-built for the Broadcom ACFJ-3540T, with an input voltage range from 8-18V and an output of 20V/1.5W. It has successfully passed a rigorous 10G vibration reliability test, making it highly reliable in motor environments. This platform also meets the stringent requirements of a 6.2mm creepage distance and complies with IEC60664 for basic insulation.
“We are delighted to report an overwhelming market interest in our pre-existing industrial-grade version and the extensive range of applications it caters to. The customized EP9 bobbin is specially designed to operate flawlessly in critical motor drive environments, boasting a 6.2mm creepage distance and basic insulation that provides isolated power solutions for the IGBT inverter circuit. As an AEC-Q200 and 10G vibration-qualified product, it continues to be the most trusted and reliable solution for even the most demanding applications.”
Gerard Healy | Product Marketing, Power PBU, Pulse Electronics
The winding is fully automated, making this product well suited for high-performance, high reliability requirements in many automotive applications which also require a price competitive solution. Samples are available through the web portal here or via the Pulse distribution network.
